M90

M90 Features

● MoreFun M90 Android POS Terminal Accept all payment types
● Chip / Magstripe / NFC/ QR code / Mobile wallets
● Advanced security PCI PTS 6.x approved
● Multiple connectivities 4G / Wifi/ Bluetooth / USB
● New commerce capabilities Support variety apps
Powered by Android10, M90 is a modern designed payment terminal as smart as mobile phone,perfectly suit to any use cases.Equipped with long life battery, user-friendly interface, large memory.enable faster processing and more transactions.

Function

Inquiry Now Download to PDF

Leading Fast Charge

20W fast charging based on USB-PD protocol.

Intelligent battery protection,longer battery life.

M90 Technical Specifications

Inquiry Now

os

Android 10 Android 13 (Optional)
CPU

Cortex Quad-core A53, 2.0GHz
ARMv7-M security core, 144MHz

ARMv7-M security core, 144MHz
Memory

1GB RAM, 8GB FLASH
2GB RAM, 16GB FLASH (Optional)
MicroSD card (up to 128GB)
Magnetic Card Reader

Magnetic Card Reader
GPS

GPS/Glonass/Beidou (Optional)
Wireless Communication

4G / 3G / 2G
Wi-Fi 2.4&5GHz,802.11 a/b/g/n/ac
Bluetooth 2.1 EDR/3.0 HS/4.2 LE/5.0 LE
Display

5.99-inch 1440 x 720
Capacitive multi-touch screen
Card Reader

EMV L1/L2, conforming to ISO 7816, 1.8V/3V, synchronous & asynchronous, T=0 & T=1
Contactless Card Reader

EMV Contactless L1, conforming to ISO 14443 Type A/B, Mifare, Felica
Camera

2 MP front camera, 5 MP autofocus rear camera with flashlight,
support 1D/2D code payment (Optional)
Professional Barcode Scanner (Optional)
Audio

1 x Speaker, 1 x Microphone (Optional)
Card Slots

1 X PSAM (MINI) + 2 X SIM (MICRO + MINI)+ 1 X SD
2 X PSAM (MINI) + 1 x SIM (MICRO)+ 1 x SD (Optional)
Peripheral Ports

2 x Type C port (1 for charging, 1 for charging&communication)
Fingerprint

FAP20, FBI/STQC (Optional)
Keypad

1 x power button, 1 x VOL+/VOL-, 1 x function key
Battery

7.6V/2500mAh/19Wh (Equal to 3.8V/5000mAh)
Power Supply

Input: 100-240V AC 50/60Hz, 0.5A
Output: 5.0V DC, 2.0A
Docking Station

Charging base
1 x USB C (Only Charge)
Multifunctional base
2 x USB A (USB HOST)
1 x USB C (Only Charge)
1 x RJ11 (RS232)
1 x RJ45 (LAN)
Certifcations

EMV / PCI / Pure / Visa / Mastercard / American Express / Discover
UnionPay / Rupay / CE / FCC / RoHS
